NYBY Cable

NYBY cable are applied for power distribution in city networks, industrial plants and on the places where mechanical damages are expected. May be laid in the ground, cable ducts and in open air.

Application

Distribution power cable for static application, mostly in ground, but also in water, within facilities, in cable canals, in concrete. Used in electric power plants, transformer stations, industrial plants, metropolitan networks and other electric plants. Applied in conditions requiring protection against heavier mechanical damages, but where cables are not exposed to heavier tensile strain.

Operation Characteristic

Temperature range: during installation:-5 °C up to +50 °C fixed installed:-30 °C up to +70 °C at short circuit of max. 5 s:up to 160 °C Nominal voltage:Uο/U = 0,6/1 kV Test voltage:4 kV Maximal tensile strength:50 N/mm² Behaviour in fire:IEC 60332-1 Minimal inner bending radius: single core:15D multi core:12D Special version upon request Cross sectional area customized Aluminum conductor required

Standard

HRN HD 603 S1 IEC 60502-1 DIN VDE 0276 part 603 cables with 6 and more conductors: HRN HD 627 S1 DIN VDE 027

Cable Structure

Conductor:Cu, class 1 or 2 acc. to HRN HD 383 / IEC 60228 / DIN VDE 0295 class 1:solid, round (RE) class 2:multi wire stranded, round (RM) or sector (SM), multi wire exceeding 50 mm² are compacted Insulation:PVC compound, concentrically stranded cores, colour marked acc. to HRN HD 308 S2 / VDE 0293-308, with or without protective yellow-green conductor Filler:spouted elastomer or plastomer compound or wrapped thermoplastic tapes Armour:dtwo galvanized steel tapes Sheath:PVC compound sheath colour:black

Specifications

number of cores x conductor cross-section	Construction	Construction of individual conductor	Insulation thickness	Sheath thickness	External diameter	Cable weight
N x mm²		N x mm	mm	mm	mm	Kg/km
Power NYBY-J, NYBY-O
2 x 4	RE	1 x 2,2	1	1,8	15,3	420
2 x 6	RE	1 x 2,7	1	1,8	16,3	493
2 x 10	RM	7 x 1,34	1	1,8	18,7	668
2 x 16	RM	7 x 1,70	1	1,8	20,9	873
3 x 4	RE	1 x 2,2	1	1,8	16	476
3 x 6	RE	1 x 2,7	1	1,8	17,1	569
3 x 10	RM	7 x 1,34	1	1,8	19,7	783
3 x 16	RM	7 x 1,70	1	1,8	22,1	1044
3 x 16+10	RM/RE	7 x 1,7/7 x 1,3	1,0 / 1,0	1,8	23,2	1163
3 x 25+16	RM/RM	7 x 2,2/7 x 1,7	1,2 / 1,0	1,8	26,2	1641
3 x 35+16	SM/RM	7 x 2,5/7 x 1,7	1,2 / 1,0	1,8	28,2	1978
3 x 50+25	SM/RM	7 x 3,/7 x 2,2	1,4 / 1,2	1,9	31,9	2606
3 x 70+35	SM/RM	13 x 2,7/7 x 2,5	1,4 / 1,2	2	35,8	3471
3 x 95+50	SM/RM	17 x 2,7/7 x 3	1,6 / 1,4	2,2	42,6	4963
4 x 1,5	RE	1 x 1,37	0,8	1,8	14,2	357
4 x 2,5	RE	1 x 1,74	0,8	1,8	15,1	424
4 x 4	RE	1 x 2,2	1	1,8	17,1	555
4 x 6	RE	1 x 2,7	1	1,8	18,3	670
4 x 10	RM	7 x 1,34	1	1,8	21,2	936
4 x 16	RM	7 x 1,70	1	1,8	23,8	1265
4 x 25	RM	7 x 2,20	1,2	1,8	27	1793
5 x 4	RE	1 x 2,2	1	1,8	18,3	640
5 x 16	RM	7 x 1,70	1	1,8	25,8	1472
5 x 50	SM	7 x 3,00	1,4	2,1	37	3498
5 x 70	SM	13 x 2,70	1,4	2,2	42,6	4956
5 x 95	SM	17 x 2,70	1,6	2,4	50	6748
5 x 120	SM	18 x 3,00	1,6	2,6	53,1	7941
